FABOOL Laser CO2

$2,598.00 USD

FABOOL Laser CO2 is the world's largest ready-to-assemble laser cutter and engraver. It uses a high-power CO2 laser tube, and has a cutting area as big as 23.6×17.3inch(600×440mm).
Packing List

Description
Laser Cutter and Engraver

Ready-to-assemble Laser Cutter and Engraver

Sufficient Machine Performance

Large Working Area:23.6×17.3inch

Maximum thickness for cutting:0.39inch

Works on any material you can think of

Wooden

Leather

Cardboard

Paper

Fabric

Denim

Rubber

Anodized aluminum

Acrylic

Cork

Low Price

By using open source software and providing the buyer's self-assemble model, we created a low-priced laser cutter and engraver.

User-friendly Software

The free all-in-one software includes functions like creating and retrieving the processed data of products. Learn more

Open Source

FABOOL Laser series are open sauce, including all mechanical, electronical, and software. You can see all stractures.

Suggested Accessories

For optimal working height

Workbench

By placing the main body on top, it becomes the perfect height for getting your work done. Recommended because of the FABOOL Laser CO2's relatively large size.

For fire prevention and safety

Flame Damper Kit

When using our high-power laser cutter, it is strongly recommended to use the Flame Damper Kit when processing materials that can emit fire. Flames are prevented by applying air to the irradiated part of the laser light using a compressor. *If you can not purchase a Flame Damper Kit, be sure to take other anti-inflammatory precautions.

For preventing the loss of small parts

Working Bed (Honeycomb)

A honeycomb-design processing bed that prevents products from falling when processing small parts. The ability to detach post-assembly allows for easy cleaning and maintenance.

For dispelling smoke / odors

Exhaust Fan Kit

An extension part for dispelling smoke and odors out of the working area. The FABOOL Laser CO2 comes pre-set with a ventilation port, making it possible to conveniently dispel smoke and odors accumulated in the product by connecting the exhaust duct.

For fast, safe mirror lens adjustmentss

Laser Tube (w/ Laser Pointer)

A laser tube equipped with a laser pointer. Light is focused at the same point as the laser's irradiation, making it possible to perform optical axis (mirror / lens position) adjustments at the time of assembly and maintenance more safely and quickly (cutting the typical time from several hours to about 30 minutes).

For making mirror / lens adjustments easier

Optical Adjustment Button

Useful when performing optical axis (mirror / lens position) adjustments at the time of assembly and maintenance. Since the laser output can be controlled by hand with the press of a button, adjustments to the mirror and lens positions can be performed much easier. Laser output intensity can be adjusted by hand as well.

For determining processing position / range

Positioning Kit

Light from the laser pointer is focused on the beam of the laser cutter, making it very easy to confirm and adjust the starting point and cutting area. If purchasing only the Positioning Kit, the Laser Pointer's light is a dot, but this can be changed by using either the Laser Pointer (Cross) . *The connection cables for the Laser Pointer (Cross) are sold separetely.

Spec

Work Area 23.6×17.3inch (600×440mm)
Laser CO2 Laser
Supported Processing Method Vector engraving, Raster engraving
Supported OS Windows7 and more, Mac10.11.6 El capitan and more
Supported File png, jpeg, jpg, bmp, gif, tiff, tif, svg, dxf
Accessories Protection glasses, USB cable, AC cable
Power Supply AC110V (50Hz/60Hz) / AC220V (50Hz)
Size 35.8×32.2×14.9inch (910×820×380mm)
Operating temperature 68F (20℃) to 86F (30℃)
Continuous operating time Under 30 minutes
A recommended environment Temperature : 41F (5℃) to 104F (40℃), Humidity : 25% to 50%
Weight About 110lbs (50kg)

*Please refer to FAQ for other specifications.

*These specifications may change as the product upgrades.

Caution
Laser radiation is very dangerous. Please watch for fire. It can cause burns and damage to the eyes if not careful. The user -is responsible for any damages and losses that may occur through the use of the machine.
Assembly
This product requires self-assembly. Please read the manual provided on our website beforehand.
The edges of the acrylic plates and stainless steel plates are very sharp. Please wear gloves to prevent from cutting your hands.
Please make sure that all screws and nuts are tightly fixed before operating the machine.
Please read the instruction manual first to see whether it is feasible to assemble on your own.
Product Warranty
If there are any bugs or defects on parts, please report to us within 30 days of delivery. We will fix or exchange the machine free of charge. We cannot take care of any damages other than initial failures.
Please do not use over 30 minutes continuously and at temperatures over 86F. Damages caused by not following these instructions will not be covered under warranty.
